SHT31温度传感器

功能说明

Humidity

• Typ. relative humidity accuracy 2% RH

• Operating relative humidity range 0 - 100 %RH

• Response time (τ63%) 8s

• Calibration certificate Factory calibration

Temperature

• Typ. temperature accuracy 0.2 °C

• Response time (τ63%) > 2s

引脚说明

VIN：电源电压，2.4V ~ 5.5V，推荐3.3V
GND：电源地
SCL：I2C时钟
SDA：I2C数据
AL：报警状态
AD：地址，可连接VCC或GND
